產品別名 |
ElastollanTPU,1185AWTPU |
面向地區 |
Elastollan? 1185AW
熱塑性聚氨酯彈性體（聚醚）
BASF Corp. Thermoplastic Polyurethanes
產品說明：
Elastollan? 1185AW is a polyether-based thermoplastic polyurethane (TPU) containing a plasticizer. It is specifically formulated for wire and cable, film and sheet, and extruded profile applications. It contains a non-halogenated flame retardant and is rated UL-94 V-2 in vertical flame test for wall thicknesses of 0.75, 1.5 and 3.0 mm. It also passes FAR 25.853 (A) flame test. It exhibits excellent abrasion resistance, toughness, transparency, very good low temperature flexibility, hydrolytic stability and fungus resistance. It has excellent damping characteristics and outstanding resistance to tear propagation. Elastollan? 1185A is supplied uncolored in pellet form.
Elastollan? 1185AW 物性表
| 基本信息 | |
|---|---|
| 特性 |
|
| 機構評級 |
|
| 外觀 |
|
| 加工方法 |
|
| 物理性能 | 額定值 | 單位制 | 測試方法 |
|---|---|---|---|
| 比重 | 1.16 | g/cm3 | ASTM D792 |
| 熔流率（熔體流動速率） (190°C/3.8 kg) | 5.0 到 25 | g/10 min | ASTM D1238 |
| 硬度 | 額定值 | 單位制 | 測試方法 |
|---|---|---|---|
| 肖氏硬度 (邵氏 A) | 85 | ASTM D2240 |
| 機械性能 | 額定值 | 單位制 | 測試方法 |
|---|---|---|---|
| 拉伸模量 (注塑) | 19.3 | MPa | ASTM D412 |
| 彎曲模量 (注塑) | 20.7 | MPa | ASTM D790 |
| 泰伯耐磨性 | 35.0 | mg | ASTM D1044 |
| Abrasion - DIN | 30 | mm3 | DIN 53516 |
